Galvanized steel end (run-on) roller M with a support bearing for cantilever sliding gates. Compatible with 95×81 mm guide rails. Rated for loads up to 800 kg.
The M end roller is installed inside the guide beam of cantilever sliding gates. When the gate is closed, the roller runs into the bottom catcher, removing the load from the main roller carriages and increasing the reliability and durability of the entire gate system.
The roller is made of galvanized carbon steel and is equipped with a support bearing for smooth and silent operation. Compatible with 95×81 mm guide rails and designed for gate structures weighing up to 800 kg.
Fastening elements material — galvanized carbon steel. The product is not subject to mandatory certification. Made in 2026 in Ukraine.
Specifications:
- Type: steel end roller for cantilever sliding gates
- Model: 1530. End roller M
- Guide rail compatibility: 95×81 mm
- Roller material: galvanized carbon steel
- Support bearing: present
- Maximum load: up to 800 kg
- Weight: 0.8 kg / pc.
- Country of manufacture: Ukraine
- Certification: not subject to mandatory certification
- Price: per 1 pc
