Galvanized roller carriage for cantilever and hanging sliding gates, compatible with a 95×81 mm guide rail. Equipped with rollers on 203 series bearings, designed for loads up to 800 kg for cantilever gates and up to 1000 kg for hanging gates. Made of galvanized carbon steel. Made in Ukraine.
The roller carriage for cantilever and hanging sliding gates is designed for reliable and stable operation of gate structures in various configurations. Fully compatible with a 95×81 mm guide rail, making it a universal solution for private and industrial properties.
The rollers are equipped with 203 series bearings, which ensure smooth, stable, and quiet gate movement even under heavy use. The maximum load capacity is up to 800 kg for cantilever gates and up to 1000 kg for hanging sliding gates.
In hanging structures consisting of 8 rollers, the 4 outer rollers are engaged under working load, which ensures even weight distribution and increases the service life of the carriage.
The carriage body is made of galvanized carbon steel, resistant to corrosion, mechanical stress, and temperature changes. The product is not subject to mandatory certification and is fully suitable for long-term operation.
Specifications:
Type: roller carriage for sliding gates
Gate type: cantilever and hanging
Rail compatibility: 95×81 mm
Bearing: 203 series
Maximum load: up to 800 kg (cantilever), up to 1000 kg (hanging)
Material: galvanized carbon steel
Weight: 5 kg / pc
Production: Ukraine
Certification: not subject to mandatory certification
Price: per 1 pc
A reliable solution for those looking for a durable, long-lasting, and heavy-duty roller carriage for sliding gates.
