Non-galvanized GRAND 140×140 mm guide rail — a reinforced cantilever beam for heavy-duty industrial sliding gates weighing up to 1800 kg. It provides high rigidity, stable geometry, and smooth gate operation. Suitable for cantilever gates with a maximum entrance width of up to 14 meters. Material: high-carbon non-galvanized industrial-grade steel. Weight — 10.5 kg/m, supplied per linear meter; solid profile lengths available: 5, 6, and 7 meters.
The GRAND 140×140 mm guide rail is a durable non-galvanized cantilever beam designed for manufacturing heavy industrial sliding gates and sliding metal structures with high operational loads. It is used at commercial and industrial facilities where maximum reliability and long service life of the guide system are required.
Thanks to its increased 140×140 mm cross-section, the guide rail features high bending rigidity and resistance to deformation. The beam confidently withstands working loads of up to 1800 kg, maintaining correct gate geometry even under intensive operation, large spans, and entrance widths of up to 14 meters (for cantilever sliding gates).
The actual weight of the guide rail is 10.5 kg per linear meter, providing an optimal balance between structural strength and ease of installation. Supply is made per linear meter; solid profiles are available in lengths of 5, 6, and 7 meters, allowing for an accurate calculation of the required material volume without overpayment.
The GRAND 140×140 guide rail is compatible with the corresponding roller carriages and guarantees smooth, stable, and quiet operation of industrial cantilever gates throughout their entire service life.
Main specifications
- Type: guide beam (cantilever)
- Size (W/H): 140×140 mm
- Permissible load: up to 1800 kg
- Maximum entrance width (cantilever gates): up to 14 m
- Material: high-carbon non-galvanized industrial-grade steel
- Weight: 10.5 kg/m
- Supply: per linear meter, profile lengths 5 / 6 / 7 m
- Price indicated: per 1 linear meter
- Application: heavy-duty industrial sliding (cantilever) gates
