Кронштейн поддерживающий для балки откатных ворот 140×140

Galvanized GRAND support bracket with a support roller. Specifically designed for cantilever sliding gates weighing up to 1800 kg. Compatible with the 140×140 mm guide rail. It relieves the load from the support roller carriages when the gate is in the open position, preventing system deformation.

The GRAND support bracket (model 5620) is a crucial hardware component for heavy-duty industrial gates. It is installed to support the free end of the 140×140 mm guide beam in the open position. Equipped with a support roller, the bracket ensures a smooth entry for the beam and reliable fixation, significantly extending the service life of the bearings in the main support carriages.

The product is made of high-strength carbon steel with a high-quality galvanized finish, ensuring protection against corrosion in all weather conditions.

Specifications:

• Type: support bracket with roller
• Compatibility: for beam (W/H) 140×140 mm
• Load capacity: up to 1800 kg
• Material: galvanized carbon steel
• Weight: 4.2 kg/pc
• Certification: not subject to mandatory certification
• Production: Ukraine
• Price: per 1 unit
