5310. GRAND Guide Assembly — 4-roller top guide with bracket

GRAND Guide Rollers with Bracket (4 rollers) — a reinforced hardware component for heavy-duty industrial sliding gates and moving structures. The unit features a U-shaped bracket made of industrial-grade high-carbon steel, ensuring maximum rigidity and stable operation under loads up to 1800 kg.

The four-roller design provides even load distribution, smooth travel, and precise vertical guidance of the gate leaf, preventing swaying caused by wind or mechanical forces. The high-quality steel construction and reinforced rollers make this assembly ideal for high-intensity industrial facilities.

Two roller options are available: rubber Ø32 mm (minimum distance 50 mm) or reinforced Ø45 mm (minimum distance 35 mm). The assembly is delivered pre-assembled and ready for installation.

Specifications:

• Type: guide rollers with bracket
• Number of rollers: 4 pcs
• Bracket material: High-carbon non-galvanized industrial-grade steel
• Maximum load: up to 1800 kg
• Kit weight: 5.5 kg
• Contents: bracket + 4 rollers
• Price: per kit
• Certification: not subject to mandatory certification
