Sliding Gate Hardware Kit №4 for gates up to 400 kg (opening up to 4 m) with Polymer Rollers

Looking to build reliable and durable sliding gates yourself? Hardware Kit No. 3 is a time-tested solution for those who value strength. The set is equipped with metal rollers, ensuring maximum resistance to wear and heavy loads.

Main Advantage: Metal Rollers

Unlike polymer alternatives, steel rollers have an increased service life in harsh weather conditions. They are resistant to temperature fluctuations and designed for intensive use. This is the ideal choice for gates with heavy cladding.

Technical Specifications (Load vs. Width):

• Weight up to 500 kg: for opening widths up to 3 meters;
• Weight up to 450 kg: for opening widths up to 3.5 meters;
• Weight up to 400 kg: for opening widths up to 4 meters;
• Weight up to 350 kg: for opening widths up to 4.5 meters;
• Guide rail wall thickness: 3.0 mm (high-quality steel);
• Bearing type: Reliable 201 series support bearing (301 - optional);
• Rail finish: Black steel (basic version);
• Country of manufacture: Ukraine.

Please note: upon request, the kit can be assembled with a galvanized guide rail for maximum corrosion protection.

Kit Contents:

	Small guide rail C 69×58 mm (item 1112) Length: 5 / 6 / 7 meters to choose from.
	Roller carriage No. 2 with METAL rollers (item 1220) Quantity: 2 pcs. Powerful steel wheels for long-term service.
	Top guide No. 2 with 2 rollers (item 1320) Quantity: 1 pc. Bracket with guide rollers.
	Bottom catcher No. 2 with 76 mm shelf (item 1420) Quantity: 1 pc.
	End roller No. 2 70×60 mm (item 1520) Quantity: 1 pc.
	Small end cap 70×60 mm (item 1620) Quantity: 2 pcs.

Why Choose This Specific Kit?

• Enhanced Stability: Metal rollers withstand shock loads better when the gate is closing.
• Structural Reliability: The 3 mm thick rail ensures the stable geometry of your gate for many years.
• Affordable Price: Direct supply from the Ukrainian manufacturer without extra markups.

Order Hardware Kit No. 3 today to provide your gates with strength and trouble-free operation for decades!
